DAS Audio WR-8826-DX 200W Two-Way Full Range Speaker
DESCRIPTIONÂ
The WR-8826-DX employs twin 6B woofers for low frequency reproduction. A 1” annular diaphragm compression driver provides brilliant highs. The birch plywood cabinet construction offers an ultra-compact design which is available in black, white or military grey depending on the finish.
The WR-8826-DX offers two exposure ratings: CX (covered exposure) for applications where cabinets are covered or protected, and DX (direct exposure) where cabinets are unprotected and directly exposed to the environment. The CX versions are protected with a thick ISO-flex polyurea coating. The DX versions augment the protection rating by employing a fiberglass exterior. Stainless steel fittings and mounting hardware are offered on both versions.
SPECIFICATIONSÂ
- Frequency Range (-10 dB): 70 Hz – 22 kHz
- Horizontal Coverage (-6 dB): 80Âş
- Vertical Coverage: 80Âş
- Nominal Impedance: 16 ohms
- RMS Power Handling: 200 W
- Peak Power Handling: 800 W
- On-axis Sensitivity 1W/1 m: 93 dB SPL
- Maximum Peak SPL at 1 m: 122 dB
-
Recommended Amplifier:Â
- INTEGRAL-A402
INTEGRAL-A404
INTEGRAL-A1002
INTEGRAL-A1004
INTEGRAL-A1602
INTEGRAL-A1604
INTEGRAL-MA1004
INTEGRAL-MA1604
- INTEGRAL-A402
-
Recommended Processor:Â
- INTEGRAL-M88
INTEGRAL-MA1604
INTEGRAL-MA1004
- INTEGRAL-M88
- Audio Input Connector: Covered Barrier Strip Terminals
- Audio Output Connector: Covered Barrier Strip Terminals
- Enclosure Construction: Birch Plywood
- Enclosure Geometry: Trapezoidal
- Rigging: M10 Rigging Points
- Finish: Fiberglass
- Color: Black
$2,027.00
